Home > Product > Resistor

Resistor · 고전압 저항

CADDOCK KAMAYA Tama
E&C nicrom TKK
EBG PCN Viking
Genvolt SRT


SMD - High Voltage, Low Noise Resistors
HVC : 0.10~2W, 600~5000V, ±0.05(A)~±20(M)%, ±5~±100ppm, 1K~100GΩ
SMD/Plate - High Voltage, Precision, Non-Inductive Resistors
90/100/200 : 0.80~9W, 5k~60kV, ±0.05(A)~±10(K)%, ±5~±100ppm, 1K~100GΩ
High Voltage, Precision, Non-Inductive, Low TC Resistors
400 : 3.80~20W, 15k~90kV, ±0.05(A)~±10(K)%, ±5~±100ppm, 1K~100GΩ
High Voltage, Precision, Non-Inductive, Low TC Resistors
MX400 : 3.80~20W, 15k~90kV, ±0.05(A)~±10(K)%, ±5~±100ppm, 1K~100GΩ
High Voltage, High Precision, Low TC Resistors
HVD : 30~45W, 75k~200kV peak, ±0.05(A)~±1(F)%, ±5~±100ppm, 1K~100GΩ
Divider - High Voltage, High Precision, Low TC
300 : 0.75~4.5W, 12k~55kV, ±0.05(A)~±10(K)%, ±5~±100ppm, 1K~100GΩ
Divider - High Voltage, High Precision, Low TC
XHVD : 30~45W, 75k~200kV peak, ±0.05(A)~±1(F)%, ±5~±100ppm, 1K~100GΩ
Divider - High Voltage, High Precision, Low TC
600 : 15~75W, 70k~120kV, ±0.05(A)~±5(J)%, ±5~±100ppm, 1K~100GΩ
High Voltage, Precision, Non-Inductive, Low TC Resistors
500 : 15~110W, 35k~150kV, ±0.05(A)~±10(K)%, ±5~±100ppm, 1K~100GΩ
Ultra High Voltage, Non-Inductive Resistors
1000 : 150~300W, 200k~400kV, ±0.05(A)~±10(K)%, ±5~±100ppm, 1M~100GΩ
High Power, Non-Inductive Resistors
TO : 300V, ±1(F)~±5(J)%, ±50/±100ppm, 0.05Ω~10KΩ
2~6W in free air, 30~120W on heat sink
High Power, Planar Non-Inductive Resistors
TP : 50~100W, 300V, ±1(F)~±20(M)%, ±150ppm, 1Ω~10KΩ
Low TC Power Film Resistors
N685 TNK : 0.75W, 300V, ±0.01(T)~±1(F)%, ±5~±25ppm, 1KΩ~1MΩ
N685 MK : 0.75W, 2000V, ±0.1(B)~±1(F)%, ±50ppm, 1Ω~350MΩ
Surge Protection Power Resistors
NI03 : 0.5~2W, 3k~11kV, ±1(F)~±10(K)%, ±100ppm, 100Ω~100KΩ
